| Part No. | Chain Size (mm) | WLL @ 60 Deg. (t) | H (mm) | J (mm) | K (mm) | T (mm) | U (mm) | V (mm) | Weight (kg) |
|---|---|---|---|---|---|---|---|---|---|
| 1313006 | 6 | 2.4 | 145 | 90 | 20 | 120 | 63 | 14 | 1.8 |
| 1313008 | 8 | 4.3 | 160 | 90 | 23 | 70 | 34 | 16 | 2.4 |
| 1313010 | 10 | 6.9 | 180 | 100 | 27 | 85 | 40 | 19 | 3.8 |
| 1313013 | 13 | 11.6 | 200 | 110 | 33 | 115 | 50 | 23 | 6.6 |
| 1313016 | 16 | 17.3 | 275 | 150 | 38 | 140 | 65 | 27 | 11.5 |
| 1313020 | 20 | 27.7 | 350 | 190 | 50 | 150 | 70 | 33 | 23 |
| 1313022 | 22 | 32.9 | 350 | 250 | 56 | 170 | 75 | 36 | 31 |
