| Part No. | Chain Size (mm) | Legs | Length (mtrs) | Direct WLL (t) | 60 Deg. WLL (t) | 90 Deg. WLL (t) | 120 Deg. WLL (t) |
|---|---|---|---|---|---|---|---|
| 198411 | 13 | 1 | 1 | 6.7 | – | – | – |
| 198412 | 13 | 1 | 2 | 6.7 | – | – | – |
| 198413 | 13 | 1 | 3 | 6.7 | – | – | – |
| 198414 | 13 | 1 | 4 | 6.7 | – | – | – |
| 198415 | 13 | 1 | 5 | 6.7 | – | – | – |
| 198416 | 13 | 1 | 6 | 6.7 | – | – | – |
| 198421 | 13 | 2 | 1 | – | 11.6 | 9.4 | 6.7 |
| 198422 | 13 | 2 | 2 | – | 11.6 | 9.4 | 6.7 |
| 198423 | 13 | 2 | 3 | – | 11.6 | 9.4 | 6.7 |
| 198424 | 13 | 2 | 4 | – | 11.6 | 9.4 | 6.7 |
| 198425 | 13 | 2 | 5 | – | 11.6 | 9.4 | 6.7 |
| 198426 | 13 | 2 | 6 | – | 11.6 | 9.4 | 6.7 |
| 198431 | 13 | 3 | 1 | – | 11.6 | 9.4 | 6.7 |
| 198432 | 13 | 3 | 2 | – | 11.6 | 9.4 | 6.7 |
| 198433 | 13 | 3 | 3 | – | 11.6 | 9.4 | 6.7 |
| 198434 | 13 | 3 | 4 | – | 11.6 | 9.4 | 6.7 |
| 198435 | 13 | 3 | 5 | – | 11.6 | 9.4 | 6.7 |
| 198436 | 13 | 3 | 6 | – | 11.6 | 9.4 | 6.7 |
| 198441 | 13 | 4 | 1 | – | 11.6 | 9.4 | 6.7 |
| 198442 | 13 | 4 | 2 | – | 11.6 | 9.4 | 6.7 |
| 198443 | 13 | 4 | 3 | – | 11.6 | 9.4 | 6.7 |
| 198444 | 13 | 4 | 4 | – | 11.6 | 9.4 | 6.7 |
| 198445 | 13 | 4 | 5 | – | 11.6 | 9.4 | 6.7 |
| 198446 | 13 | 4 | 6 | – | 11.6 | 9.4 | 6.7 |
13mm Chain Sling Assembly (G100)
13mm G100 Chain Slings complete with shortening hooks are used in a wide range of lifting applications and are ideal for construction, infrastructure, building industries.
- Pre-assembled, NATA tested, tagged and available ex-stock.
- Traditional design with eye grab hooks and clevis self locking hook.
- NATA Accredited test certificates supplied.
