RS Eyebolt, Metric Thread

The RUD RS Eyebolt is one of the leading lifting eyebolts on the market. Higher WLL in comparison to DIN 580.


  • Higher WLL in comparison to DIN 580
  • Clear marking of the minimum WLL
  • Comprehensive range of threads


Product brochure coming soon
Product manual coming soon


Part No. WLL (tonnes) M (mm) T (mm) A (mm) B (mm) C (mm) D (mm) E (mm) Weight (kg)
61401 0.1t 6 34 12 11 10 25 25 0.1
61402 0.2t 8 34 12 11 10 25 25 0.1
56397 0.25t 10 34 15 11 10 25 25 0.1
56398 0.4t 12 41 18 13 12 30 30 0.18
56403 0.75t 14 21 15 48 14 35 35 0.3
56404 1t 16 48 24 15 14 35 35 0.3
53850 1.2t 18 55 30 17 16 40 40 0.45
56407 1.5t 20 55 30 17 16 40 40 0.47
53346 1.5t 22 70 36 21 20 50 50 0.87
56408 2t 24 70 36 21 20 50 50 0.89
53347 2t 27 85 45 26 24 60 60 1.6
56409 3t 30 85 45 26 24 60 60 1.62
57770 3t 33 130 50 43 38 90 100 6.1
56954 4t 36 130 54 43 38 90 100 6.5
57771 5t 39 59 43 130 38 90 100 6.5
56955 6t 42 63 43 130 38 90 100 6.5
58044 7t 45 130 67 43 38 90 100 6.5
56956 8t 48 67 43 130 38 90 100 6.5
